Atom Hydrogen

The set of multifunction inputs and modular architecture of outputs allows using this controller to solve any technical problems, even if these tasks provide periodic change of types of input signals and types of loads. Change the configuration of outputs and inputs in real time without any tools.

706,00  +PVM

- - -

Functional elements

Atom Carbon N with numbers
1. 9-48V DCpower supply
2. CAN bus ensures synchronized operationof all Atom series devices
3. Integrate 3rd party devicesusing RS-485 interface
4. 5V and 3.3V portsfor sensors power supply
5. 12 multifunction input ports (9 in N modification)for temperature, air quality, water leakage sensors and switches connection
6. Buttonsfor navigation and control of the OLED display menu
7. Graphic OLED displayfor control and monitoring (optional for N modification)
8. Ethernet port for network connectionPossibility of remote control using the phone or voice assistants (N modification)
